BUILT TO SHINE.
Our ST3301 Series 18.6 Inch LED Light Bar is designed to offer a high volume of light in the mid-range, with excellent visibility on the road shoulders. Compared to bars like our ST4K & ST3K (which have a longer beam distance but slightly less brightness in comparison) our ST3301 forms a larger diameter spot which blends homogeneously with its wide beam. The ST3301 range is perfectly suited for the customer who is concerned about wildlife running out from the road shoulders or those who need a huge amount of brightness and coverage in the short and mid-range.
EXEMPLARY INNOVATION.
We thought that it would be time to take things up a notch! The STEDI™ ST3301 exemplifies the innovation that STEDI is known for, by making advancing strides on the popular ST3300 series. In addition to our revised reflectors, the ST3301 18.6 Inch showcases our improved lighting technology, all within a slick new look. The ST3301 Pro 18.6 Inch houses 12 x CREE™ XLamp XM-L2 LEDs, built to deliver a breakthrough lumen output. Oh, and did we mention color temperature? We’ve achieved a strong yet neutral beam character, which maintains a pleasant temperature of 5500K. If you are hoping to dramatically lift your lighting game, then look no further.
COLORS OF EXPRESSION.
Add your own personal color combination with our customizable side caps. Grey and STEDI™ orange caps are included, and when you get sick of those, indulge yourselves with the green, blue, and red caps which are available to purchase separately.
The nitty
gritty.
Unmistakable performance. Unmistakably STEDI.
For almost a decade, the name STEDI has stood for cutting-edge design and market-leading performance. STEDI has continued to keep at the forefront of LED lighting, making STEDI the leading brand born right in Australia. Unquestionably, ST3301 PRO sits at the pinnacle of the STEDI offering. A pure expression of capability and design that converges with brutal performance, making the all-new ST3301 PRO a quintessential component for any LED aficionado.
KEY TECHNICAL BREAKDOWN
- Ingress Protection IP68 (Backed by a certificate of conformity),
- Coordinated Color Temperature 5600K - Excellent color contrast.
- Flood/spot/flood combination with 12 x LEDs
- 2 Flood + 8 Spot + 2 Flood Reflector Distribution
- Tough GE Lexan primary lens which is 250 times the impact-resistant strength of glass and 30 times stronger than acrylic Poly-carbonate.
- Waterproof Deutsch DT Connector
- Adjustable Slide mounts and stainless steel side brackets are included.
- Guaranteed against electromagnetic (EMC) and radio frequency (RFI) interference
Tech Specs
LUMEN | 10,320Lm (RAW) |
PEAK INTENSITY (CANDELA) | Coming Soon |
OPERATING VOLTAGE | 10-45V DC |
WATERPROOF RATE | IP 68 |
LED | 12 x OSRAM™ |
COLOR TEMPERATURE | 5500K |
MATERIAL | Die-Cast Aluminum |
LENS | GE Lexan™ |
MOUNTING BRACKET | Aluminum |
BOLTS AND FITTINGS | 3 Series Stainless Steel |
FLOOD BEAM ANGLE | 45°C |
SPOT BEAM ANGLE | 11°C |
LUMEN MAINTENANCE | 50,000 LM-80 |
WEIGHT | 4.2lbs |
CURRENT DRAW | 6.6A @ 13.6v |
OPERATING TEMP | -40°F-140°F |
What's Included
- ST3301 Pro 18.6 INCH 12 LED LIGHT BAR
- Stainless Bolt and Nut Set
- Sliding Lower Mounting Brackets + Stainless Steel Side Brackets
- Quick-Fit High Beam Wiring Harness 12v Relay, Wiring Kit, and On/Off Switch
- 2 x Orange Side Caps
- 2 x Gray Side Caps
- HB3 and H4 Piggy Back Adaptors
